Polished 6061-T6 Aluminum 92mm Intake Manifold with Throttle Body for LS Cathedral Port Cylinder Heads

Description

92mm Sheet Metal Intake Manifold with Throttle Body for LS Cathedral Port Heads, T6061 Aluminum, Polished Finish

This intake manifold is constructed from 3mm thick T6061 aluminum sheet and features a polished finish. It is designed with a 92mm throttle body opening and includes precision CNC-machined head flanges. The manifold stands approximately 9 inches tall, which is about 5 inches higher than stock, and is equipped with three vacuum ports. TIG welding by professional craftsmen ensures consistent assembly quality.

Key Features

• Material: 3mm thick T6061 aluminum sheet
• Finish: Polished
• Manifold height: 9 inches (approximately 5 inches higher than stock)
• Throttle body opening: 92mm
• Intake overall length: 20 inches
• Vacuum ports: 3
• Precision CNC-machined head flanges
• TIG welded construction
• Designed to accommodate up to 30 lbs of boost

What’s Included

• Intake manifold assembly
• Billet aluminum 92mm throttle body
• 2x fuel rails
• Fuel crossover line
• Gaskets
• Fitting hardware

Vehicle Fitment

Fits LS-based engines with cathedral port heads, including LS1, LS2, and LS6 (4.8L, 5.3L, 5.7L, 6.0L) Chevrolet Small Block V8 Gen III/IV. Original applications include 1997-2004 Chevrolet Corvette, 1998-2002 Pontiac Firebird Formula and Trans AM, 2001-2004 Corvette Z06, 2004-2005 Cadillac CTS V-series, 2005-2007 Chevrolet Corvette, 2005-2006 Chevrolet SSR, 2006-2009 Chevrolet TrailBlazer SS, 2006-2007 Cadillac CTS V-Series, 2005-2006 Pontiac GTO, and 2008-2009 Saab 9-7X Aero.

Installation Notes

• Aftermarket intake installation may require rerouting of vacuum lines and minor adjustments on certain applications.
