Description
K Series Black High Flow Fuel Rail with AN6 Fittings and Fuel Pressure Gauge Port
This K Series high flow fuel rail is CNC machined from 6061 billet aluminum and finished with a fully anodized black coating. It features a 12.5mm (0.50”) bore diameter and is designed with side feed configuration. The fuel rail includes 8AN inlet/outlet ports and a 1/8 NPT port for a fuel pressure gauge, supporting both stock and aftermarket injectors.
Key Features
- CNC machined 6061 billet aluminum construction
- Fully anodized black finish
- 12.5mm (0.50”) bore diameter
- Side feed design
- 8AN inlet/outlet ports
- 1/8 NPT port for fuel pressure gauge
- Compatible with stock and aftermarket injectors
- Designed for use with tucked braided fuel lines
- Easy to upgrade to AN8 or AN10 fittings; kit includes AN6 fittings
What’s Included
- Fuel rail
- AN6 fittings
- Fuel pressure gauge
Vehicle Fitment
K20, K20a, K20a2, K20z, K20z1, K20z3, K24, K24a, K24a2, and other K Series engines. Honda/Acura applications.
Installation Notes
- Tested on various K Series engines with no reported fuel leaks
